· Bubble-Tight Sealing: The resilient rubber seat (EPDM, NBR, Viton optional) ensures zero leakage under PN10 / PN16 working conditions, making it an ideal choice for water and HVAC projects.
· Corrosion Resistance: The valve body is coated with high-quality epoxy powder, making it ideal for harsh environments and ensuring a professional appearance on your pipeline.
· Low Operating Torque: The polished disc design reduces friction, leading to a longer actuator life and easier manual operation.
· Universal Compatibility: Our wafer design is compatible with ANSI, DIN, and JIS flange standards, making it a versatile choice for global projects.
· Blow-out Proof Stem: Enhanced safety design to prevent stem ejection under high-pressure conditions.
Feature | Specification |
Size Range | DN40 – DN1200 (DN1200+ available upon request) |
Pressure Rating | PN10, PN16, Class 125/150 |
Body Material | CI;DI;Carbon Steel;SS304;SS316;Al-Bronze |
Disc Material | CF8;CF8M.DI+Ni;Al-Bronze |
Seat Material | EPDM;NBR;Viton;PTFE;Hypalon |
Shaft Material | SS420/SS304/SS316/SS431 |
Operation | Lever/Worm Gear/Pneumatic/Electric Actuator |
Face to Face Standard | API609/BS5155/DIN3202/ISO5752 |
Flange Standard | DIN;BS;UNI;ISO;ANSI;AS;JIS |
Mounting Flange | ISO5211 |
Working Pressure | PN10/PN16/ANSI150/PN25 |
Application | HVAC, Water Supply & Sewage, Food & Beverage, Chemical/Petrochemical/Processing, Power and Utilities, Paper and Pulp, Ship Building |
Large diameter butterfly valves up to DN2400 are available for special projects.
Why Choose Our Wafer Butterfly Valves?
As a professional butterfly valve manufacturer and exporter, WODE Valve understands that reliability is the top priority for distributors and project contractors. Each valve undergoes rigorous pressure testing before leaving our factory.
We provide:
· OEM/ODM Services: Custom logo and color options for distributors.
· Fast Lead Times: Stock available for standard sizes to meet your urgent project deadlines.
· Certified Quality: Manufactured in compliance with international standards.
· Custom-made Size:We also specialize in custom large diameter butterfly valves, including special sizes, for municipal and water treatment projects.
Looking for a Reliable Wafer Butterfly Valve Manufacturer?
WODE Valve supplies Resilient Seated Wafer Butterfly Valves for distributors, OEM partners, and engineering projects worldwide.
What we can support:
· Technical drawings & datasheets
· Free samples for OEM evaluation
· Competitive factory pricing
· Stable lead time and export packing
Contact us today to get a quotation or discuss your project requirements.
This resilient seated wafer butterfly valve is widely used in the following applications:
· Water Treatment
· Wastewater Treatment
· HVAC Systems
· Fire Protection
· Industrial Pipelines
· Power plants and cooling water systems
· Food and beverage processing (Food-grade seats)
